CNC Drilling Machine (2 Axis)

A CNC drilling machine is used for drilling holes in various materials, such as metal, plastic, and wood. The 2 axis of CNC drilling machine (2 axis) means that the machine can move the drill bit along two axes, usually the X and Y axes, which allows it to drill holes in different locations and at different depths. TCP V800 and TCP V500 are the two models of CNC drilling machine (2 axis). The machine is controlled by a computer program that is programmed to move the drill bit along the desired path and at the desired speed, based on the specifications of the job. This machine can be used for a wide range of drilling applications, from small holes in delicate materials to larger holes in thicker materials.

CNC DRILL MACHINE - TCP V500 (2 AXIS)

SPECIFICATION:
Max. Accomodate Dia. (Working) - Max. OD 500mm
Max. Drilling Capacity( U-Drill) - 40mm
Width Of Base - 375mm
X Travel - 360 Degree Indexing , Z- Traval - 400mm
X Axis - Rotary Type,
Z Axis - 35 LM Guideways,
Spindle To Chuck Distance - 300mm
Controller - Siemens,
Clamping Chuck -  300 x 4 Jaw Manual Chuck
Max. RPM - 2000RPM
Spindle Main Motor - 10HP
Lubrication System - Auto
Overall Dimension - (L x W x H) - 2200 x 1500 x 2300
Apporoximate Weight - 2000Kg.

CNC Drilling Machine - TCP-V-500 (2 Axis)

  • Feature:Low Energy Consumption
  • Motor:AC Motor
  • Automatic:Yes
  • Type:Turning Center, Horizontal
  • Bar Feeder:No
  • Material:Stainless Steel
  • Computerized:Yes
